verfügbar
IPC-130RD-Q470E-SW-FL
- 1HE lüfterlos, passiv-gekühlt
- 1x 3,5" RAID-Festplattenkäfig
- 1x PCI-E Full-Height Kartenslot
ab 2.427,00 € zzgl. Gesetzlicher MwSt.
( 2.427,00 € Basis Preis )
- SKU#: BA0005
- Kategorie: Rackmount PCs
Menge:
1HE Silent Performance Industrial PC, Kühlkonzept ohne Lüfter für absolut geräuschlose Rechenleistung, 2x SSD Wechselplatten für hohe Verfügbarkeit und Ausfallsicherheit, Optimierte Komponenten für hohe Leistung, mit integriertem Netzteil. Erweiterbar mit einer Full-Size PCIe Karte.
- 1HE lüfterloser, passiv-gekühltes Gehäuse
- 1x 3,5" Schacht extern
- 1x PCI-E Full-Height Kartenslot
Produkt | IPC-130RD-Q470E-SW-FL |
---|---|
CPU Familie | Core™ |
CPU Generation | 10. Gen Core i |
CPU Code Name | Comet Lake |
Fertigungsprozess | 14nm |
CPU TDP | 35W |
CPU Kühler | Passiver Kühlkörper |
CPU Sockel | 1200 |
Mainboard Chipsatz | Intel® Q470 |
Formfaktor Board | Mini-ITX |
Grafikprozessor | Intel® UHD Graphics 630 Gen 9,5 (Comet Lake) |
RAM Bänke | 2 |
RAM Generation | DDR4 |
RAM Maximal | 64GB |
ECC RAM | non ECC |
RAM Typ | SO-DIMM |
Kühlung | Fanless |
Audio Anschlüsse | Line-Out (grün), Mic-In (rosa) |
Gehäuse Bauform | Rack 19" |
Front Anschlüsse | 2x USB3 |
Höheneinheiten | 1HE |
Karten-Slots Gehäuse | 1 Slot |
I/O Ausbrüche | 1x ATX Panel |
M.2 Anzahl | 3 m.2 |
M.2 Slot 1 Key | Key E |
M.2 Slot 1 Formfaktor | 2230 |
M.2 Slot 2 Key | Key M |
M.2 Slot 2 Formfaktor | 2242, 2260, 2280 |
M.2 Slot 2 PCIe Lanes | x4 |
M.2 Slot 3 Key | Key B |
M.2 Slot 3 Formfaktor | 2242, 3052 |
PCIe Slots | 1 PCIe |
Kartenslot 1 Typ | PCIe |
PCIe Slot 1 Größe | x4 |
PCIe Slot 1 Generation | PCIe Gen. 3 |
PCIe Slot 1 Lanes | x4 |
Display Anschlüsse | 1x HDMI, 2x DP, 1x eDP (Embedded DP), 1x LVDS |
Display Port Version | DisplayPort 1.4 |
Mögliche COM-Ports | 4 |
COM Ports interner Pin Header | 2x RS232, 2x RS232/RS422/RS485 |
COM Standards | RS232, RS422, RS485 |
GPIO general-purpose input/output | 4xGPI 4xGPO |
Mögliche USB 2 Ports | 4 |
USB 2.0 Ports via interner Pin Header | 4x |
Mögliche USB 3 Ports | 6 |
USB 3.0 (USB 3.2 Gen 1×1) | 4x |
USB 3.0 (USB 3.2 Gen 1×1) Ports via 20-Pin Header | 2x |
Netzwerk-Chipsatz | Intel® I219LM PCIe GbE, Intel® I225LM PCIe 2,5GbE |
Netzwerkschnittstellen | 1x 1Gbit RJ45, 1x 2,5Gbit RJ45 |
RAID-Level | 0, 1, 5, 10 |
Laufwerks Anzahl | 3 Disk |
SATA Revision | SATA-3 (6Gbit/s) |
Bauform Laufwerks Slot | 3.5" |
Netzteil Bauform | Custom |
Netzteil Anschluss Buchse | C14 Kaltgeräte Buchse |
Netzteil Eingangsspannung Min. | 90V |
Netzteil Eingangsspannung Max | 264V |
Trusted Platform Module (TPM) | TPM chip on board, TPM 2.0 |
Farbe | Schwarz |
Gehäuse Material | Aluminium |
LEDs | Power LED |
Taster | Power Schalter |
Montage | Rack 19" |
Betriebssysteme | Windows 11, Windows 10, Win 10 LTSC Entry, Win 10 LTSC Value, Win 10 LTSC High End, Linux, Ubuntu |
Industriestandards | CE |
Umgebungstemperatur Betrieb | 0°C ~ 40°C (belüftet) |
Lagertemperatur | 0°C ~ 70°C |
Relative Luftfeuchtigkeit Betrieb | 5% ~ 95%, non-condensing |
Breite (mm) | 445 |
Länge (mm) | 305 |
Höhe (mm) | 44 |
